F2004B with isolated back is fire-tested by SP according to SP method 2369 with regards to outer fire-impact.
The storage cabinets can be used for instruments, accounting, electrical apparature ect. To delay the spread of fire in sensitivte enviroments and for storage in connection with evacuation paths in schools, hospitals, offices, industries ect.
Reinforced storage cabinet, fire-isolation (Euroclass A1) between double steel plates in doors, gabels, top and bottom. Flameproof powder-coating. door-handles equipped with inflection point.
Barrings are welded on the inside of the doors on the hinge-side. The doors are equipped with a reinforced profile that lies directly against the shelves when the doors are closed. The cabinet is fitted with heavy duty espagnolette-locking and cylinder lock. For storage of valuables see our fire-rated cabinets.
Trials done by The Technical Research Institute of Sweden (SP)
– Modell F2004 with isolated back is tested with resoect to external fire according to SP method 2369. No internal fire test has been made as the locker isn’t equipped with a door-closer. SP rapport 98B1,0718 rev.
– Stability and durability according to SS-EN 14073-3
– Security demands according to SS-EN 14073-2
– Durability of moving parts according to SS-EN 140747777
– Determination of strength and durability ISO 7170:2005
– quality according to SS83 90 30 edition 3
– Compliant with Möbelfaktas extra high demands on surface durability
ITEM NO: F2006B
EXT. MEASUREMENTS: H2095 x W1000 x D600 mm.
INT. MEASUREMENTS: H1930 x W925 x D560 mm.
NO OF SHELVES: 5
WEIGHT: 145 kg
ITEM NO: F2004B
EXT. MEASUREMENTS: H2095 x W1000 x D450 mm.
INT. MEASUREMENTS: H1930 x W925 x D410 mm.
NO OF SHELVES: 5
WEIGHT: 125 kg
ITEM NO: F1204E
EXT. MEASUREMENTS: H1295 x W1000 x D450 mm.
INT. MEASUREMENTS: H1130 x W925 x D410 mm.
NO OF SHELVES: 3
WEIGHT: 85 kg
ITEM NO: F806G
EXT. MEASUREMENTS: H895 x W1000 x D600 mm.
INT. MEASUREMENTS: H730 x W925 x D560 mm.
NO OF SHELVES: 1
WEIGHT: 75 kg
ITEM NO: F804G
EXT. MEASUREMENTS: H895 x W1000 x D450 mm.
INT. MEASUREMENTS: H730 x W925 x D410 mm.
NO OF SHELVES: 1
WEIGHT: 60 kg
ITEM NO: F803G
EXT. MEASUREMENTS: H895 x W1000 x D300 mm.
INT. MEASUREMENTS: H730 x W925 x D275 mm.
NO OF SHELVES: 1
WEIGHT: 50 kg
Fittings
ITEM NO: KL
DESCRIPTION: Electronic safety handle.
ITEM NO: F06
DESCRIPTION: Shelf, depth 600 mm.
ITEM NO: F04
DESCRIPTION: Shelf, depth 450 mm.
ITEM NO: F03
DESCRIPTION: Shelf, depth 300 mm.
ITEM NO: FUH 06
DESCRIPTION: Exensible shelf for depth 600 mm.
ITEM NO: FUH 04
DESCRIPTION: Exensible shelf for depth 450 mm.
ITEM NO: FHR
DESCRIPTION: Hanging file folder frame (For depth 450 mm)
